VAGAR VP-N 15/30 RS232 are tabletop retail scales for goods weighing from 100 g to 30 kg. The two weighing intervals use 5 g and 10 g divisions. The model has a 230×325 mm stainless-steel platform, LED display, moisture-resistant touch keypad, IP54 protection and two-way RS-232. The scales operate from 220 V mains power or a battery for up to 20 hours, and the two-way RS-232 cable is included.
What are VAGAR VP-N 15/30 RS232 retail scales?
VAGAR VP-N 15/30 RS232 are class III electronic retail scales with two weighing intervals up to 15 kg and 30 kg. The minimum weighing limit is 100 g, with a 5 g division in the first interval and 10 g in the second. Weight, unit price and total price are displayed on an LED screen with 14 mm characters.
Who are VAGAR VP-N 15/30 RS232 suitable for?
VAGAR VP-N 15/30 RS232 are suitable for retail locations that weigh goods from 100 g to 30 kg and need to transfer weighing data to a computer through RS-232.
- grocery stores selling goods by weight
- supermarkets and retail counters where price is calculated from weight
- market and mobile retail locations using battery-powered equipment
- warehouses and receiving areas handling loads up to 30 kg
- cafes, restaurants, packing areas and small production facilities
Not suitable for: loads heavier than 30 kg, goods lighter than 100 g, or tasks that require labels to be printed directly by the scales.
Advantages of VAGAR VP-N 15/30 RS232
VAGAR VP-N 15/30 RS232 combine two weighing intervals, battery operation, a protected touch keypad and two-way RS-232 data transfer.
- maximum weighing limit of 30 kg
- 5 g division in the first interval and 10 g in the second
- 230×325 mm stainless-steel platform
- moisture-resistant touch keypad and IP54 protection
- LED display with 14 mm characters
- operation from 220 V mains power or battery for up to 20 hours
- two-way RS-232 interface for transferring data to a computer
- weighing accumulation and electronic calibration counter
- direct price keys
- two-way RS-232 cable included
How do they differ from VAGAR VP-N 6/15 RS232?
VAGAR VP-N 15/30 RS232 are intended for heavier goods than VAGAR VP-N 6/15 RS232. The 15/30 version has a 30 kg maximum limit, a 100 g minimum limit and 5/10 g divisions. VAGAR VP-N 6/15 has a 15 kg maximum limit, a 40 g minimum limit and 2/5 g divisions. Both versions use a 230×325 mm platform, LED display and RS-232.
Where are VAGAR VP-N 15/30 RS232 used?
VAGAR VP-N 15/30 RS232 are used in retail and wholesale stores, supermarkets, markets, warehouses, cafes, restaurants, packing areas and production facilities. The operating temperature range is from -10 to +40 °C, and the built-in battery provides up to 20 hours of operation.
What is used with the scales?
The two-way RS-232 cable required for connecting VAGAR VP-N 15/30 RS232 to a computer is already included. If the computer has no COM port, use a Dynamode USB to COM adapter. A checkout workstation can use the Leabon T630 173 I5 8128 touchscreen all-in-one. Connection of Vagar VP and VP-N 6/15/30 LED scales to Torgsoft through RS-232 is covered in a dedicated setup guide.
Questions and answers
Is an RS-232 cable included with VAGAR VP-N 15/30?
Yes. The two-way RS-232 cable for connecting the scales to a computer is included. The manufacturer lists an RS232 DB9 female-to-female cable as part of the standard package.
What are the maximum and minimum weighing limits?
The maximum weighing limit is 30 kg, while the minimum weighing limit is 100 g.
What is the division of VAGAR VP-N 15/30?
The division is 5 g in the first interval up to 15 kg and 10 g in the second interval up to 30 kg.
How are the scales connected to a computer?
The scales use two-way RS-232. The included RS-232 cable is used when the computer has a suitable COM port. If only USB is available, a USB to COM adapter is required.
Can the scales operate without mains power?
Yes. VAGAR VP-N have a built-in 4 V / 4 Ah battery. The manufacturer specifies up to 20 hours of battery operation.
What is the warranty for VAGAR VP-N 15/30 RS232?
The Torgsoft product page and manufacturer specifications state a 12-month warranty period for this model.
How to choose retail scales?
Retail scales are selected by maximum and minimum weighing limits, division, platform size, power source and computer interface. VAGAR VP-N 15/30 RS232 are intended for goods from 100 g to 30 kg and use 5/10 g divisions. If goods do not exceed 15 kg and a 2/5 g division is required, consider the VAGAR VP-N 6/15 version.
